TF-M20F-09120 4.5V 25500rpm 有刷電機
馬達特點:
低噪音
馬達壽命長
高精度
型號: TF-M20F-09120
電壓: 1.0-6.0V
重量: 4.0g
CONDITION @ 4.5V | TYPE類型 | VALUE數(shù)值 | TOLERANCE公差 |
NO LOAD空載 | SPEED速度 (rpm) | 25500 | ±15% |
CURRENT電流 (A) | 0.055 | 0.07MAX | |
AT MAXIMUM EFFICIENCY 最大功率 | SPEED速度 (rpm) | 20446 | ±15% |
CURRENT 電流(A) | 0.22 | 0.27MAX | |
TORQUE扭力 (mN.m) | 0.23 | 0.19MIN | |
TORQUE 扭力(g.cm) | 2.38 | 1.9MIN | |
OUTPUT輸出功率 (W) | 0.50 | 0.4MIN | |
EEP效率 (%) | 49.82 | 39.9MIN | |
STALL堵轉(zhuǎn) | TORQUE扭力 (mN.m) | 1.18 | 0.94MIN |
TORQUE扭力 (g.cm) | 12 | 9.6MIN | |
CURRENT電流 (A) | 0.9 | 1.08MAX |
